SGU20N40LTU
RoHS
RoHS compliant
RoHS compliantPackage TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Through Hole Trench SINGLE IGBT Transistor 8V @ 4.5V 150A 150A 45W 1800ns
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.188
≥1 USD $1.188
Inventory: 58852
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Collector Pulsed (Icm) 150A
IGBT Type Trench
Turn Off Time-Nom (toff) 1800 ns
Vce(on) (Max) @ Vge, Ic 8V @ 4.5V, 150A
Turn On Time 1900 ns
Voltage - Collector Emitter Breakdown (Max) 400V
Polarity/Channel Type N-CHANNEL
Transistor Application GENERAL PURPOSE SWITCHING
Power - Max 45W
Input Type Standard
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSIP-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Additional Feature LOW CONDUCTION LOSS
Terminal Finish NOT SPECIFIED
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Mounting Type Through Hole
