SGP20N60HSXKSA1

Rochester Electronics, LLC
RoHS
RoHS RoHS compliant
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Tube Through Hole NPT ROHS3Compliant IGBT Transistor 3.15V @ 15V 20A 36A 178W 18ns/207ns
PDF
/
Inventory: 2506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Switching Energy 690μJ
Td (on/off) @ 25°C 18ns/207ns
Current - Collector Pulsed (Icm) 80A
Gate Charge 100nC
IGBT Type NPT
Vce(on) (Max) @ Vge, Ic 3.15V @ 15V, 20A
Test Condition 400V, 20A, 16Ohm, 15V
Current - Collector (Ic) (Max) 36A
Voltage - Collector Emitter Breakdown (Max) 600V
Power - Max 178W
Input Type Standard
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tube
Operating Temperature -55°C~150°C TJ

Physical

Supplier Device Package PG-TO220-3-1
Package / Case TO-220-3
Mounting Type Through Hole
