NGTB30N60SWG image
Favorite
NGTB30N60SWG image
Favorite
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Tube Through Hole Trench Field Stop ROHS3Compliant IGBT Transistor 2.2V @ 15V 30A 60A 189W 200ns
PDF
/
Inventory: 2019
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Switching Energy 750μJ (on), 540μJ (off)
Td (on/off) @ 25°C 57ns/109ns
Current - Collector Pulsed (Icm) 120A
Gate Charge 90nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 2.2V @ 15V, 30A
Test Condition 400V, 30A, 10Ohm, 15V
Current - Collector (Ic) (Max) 60A
Voltage - Collector Emitter Breakdown (Max) 600V
Reverse Recovery Time 200ns
Power - Max 189W
Input Type Standard
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tube
Operating Temperature -55°C~150°C TJ

Physical

Supplier Device Package TO-247
Package / Case TO-247-3
Mounting Type Through Hole
