NGB8206NTF4
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tape & Reel (TR) Surface Mount N-CHANNEL SINGLE WITH BUILT-IN DIODE AND RESISTOR IGBT Transistor 1.9V @ 4.5V 20A 20A 150W -/5mus
PDF
/
Inventory: 6679
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Td (on/off) @ 25°C -/5μs
Current - Collector Pulsed (Icm) 50A
Turn Off Time-Nom (toff) 18500 ns
Vce(on) (Max) @ Vge, Ic 1.9V @ 4.5V, 20A
Test Condition 300V, 9A, 1k Ω, 5V
Turn On Time 6500 ns
Current - Collector (Ic) (Max) 20A
Voltage - Collector Emitter Breakdown (Max) 390V
Polarity/Channel Type N-CHANNEL
Transistor Application AUTOMOTIVE IGNITION
Power - Max 150W
Input Type Logic
Case Connection COLLECTOR
Configuration SINGLE WITH BUILT-IN DIODE AND RESISTOR
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSSO-G2
Pin Count 4
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position SINGLE
Terminal Finish TIN LEAD
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
