ISL9V5036P3
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
EcoSPARK? Tube Through Hole N-CHANNEL IGBT Transistor 1.6V @ 4V 10A 46A 250W -/10.8mus
PDF
/
Buying Options
Total Price: USD $2.69
Unit Price: USD $2.6904
≥1 USD $2.6904
≥200 USD $2.2078
≥400 USD $2.13845
≥800 USD $2.07005
Inventory: 5224
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~175°C TJ
Packaging Tube
Series EcoSPARK?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 3
Terminal Finish MATTE TIN
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE AND RESISTOR
Case Connection COLLECTOR
Input Type Logic
Power - Max 250W
Transistor Application AUTOMOTIVE IGNITION
Polarity/Channel Type N-CHANNEL
JEDEC-95 Code TO-220AB
Voltage - Collector Emitter Breakdown (Max) 390V
Current - Collector (Ic) (Max) 46A
Turn On Time 2800 ns
Test Condition 300V, 1k Ω, 5V
Vce(on) (Max) @ Vge, Ic 1.6V @ 4V, 10A
Turn Off Time-Nom (toff) 13600 ns
Gate Charge 32nC
Td (on/off) @ 25°C -/10.8μs
Compliance
RoHS Status ROHS3 Compliant
