IRGR4607DPBF
RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Surface Mount Non-RoHS Compliant IGBT Transistor 2.05V @ 15V 4A 11A 58W 48ns
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.248998
≥1 USD $2.248998
≥200 USD $0.870453
≥500 USD $0.840256
≥1000 USD $0.824501
Inventory: 6509
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Switching Energy 140μJ (on), 62μJ (off)
Td (on/off) @ 25°C 27ns/120ns
Current - Collector Pulsed (Icm) 12A
Gate Charge 9nC
Vce(on) (Max) @ Vge, Ic 2.05V @ 15V, 4A
Test Condition 400V, 4A, 100Ohm, 15V
Current - Collector (Ic) (Max) 11A
Voltage - Collector Emitter Breakdown (Max) 600V
Reverse Recovery Time 48ns
Power - Max 58W
Input Type Standard
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature -40°C~175°C TJ
Physical
Supplier Device Package D-Pak
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
