IRGB4064DPBF image
Favorite
IRGB4064DPBF image
Favorite
RoHS
RoHS RoHS compliant
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Tube Through Hole Trench ROHS3Compliant IGBT Transistor 1.91V @ 15V 10A 20A 101W 62ns
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 129
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB

Technical

Operating Temperature -55°C~175°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Input Type Standard
Power - Max 101W
Reverse Recovery Time 62ns
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 20A
Test Condition 400V, 10A, 22Ohm, 15V
Vce(on) (Max) @ Vge, Ic 1.91V @ 15V, 10A
IGBT Type Trench
Gate Charge 21nC
Current - Collector Pulsed (Icm) 40A
Td (on/off) @ 25°C 27ns/79ns
Switching Energy 29μJ (on), 200μJ (off)

Compliance

RoHS Status ROHS3 Compliant
