IRG4RC10KDTRPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tape & Reel (TR) Surface Mount ROHS3Compliant IGBT Transistor 2.62V @ 15V 5A 9A 38W 28ns
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 10031
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package D-Pak
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Input Type Standard
Power - Max 38W
Reverse Recovery Time 28ns
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 9A
Test Condition 480V, 5A, 100Ohm, 15V
Vce(on) (Max) @ Vge, Ic 2.62V @ 15V, 5A
Gate Charge 19nC
Current - Collector Pulsed (Icm) 18A
Td (on/off) @ 25°C 49ns/97ns
Switching Energy 250μJ (on), 140μJ (off)
Compliance
RoHS Status ROHS3 Compliant
