IRG4PC40UPBF image
Favorite
IRG4PC40UPBF image
Favorite
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Bulk Through Hole ROHS3Compliant IGBT Transistor 2.1V @ 15V 20A 40A 160W 34ns/110ns
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.3713
≥1 USD $5.3713
≥10 USD $4.40705
≥100 USD $4.2693
≥500 USD $4.13155
≥1000 USD $3.9938
Inventory: 1139
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Switching Energy 320μJ (on), 350μJ (off)
Td (on/off) @ 25°C 34ns/110ns
Current - Collector Pulsed (Icm) 160A
Gate Charge 100nC
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 20A
Test Condition 480V, 20A, 10Ohm, 15V
Current - Collector (Ic) (Max) 40A
Voltage - Collector Emitter Breakdown (Max) 600V
Power - Max 160W
Input Type Standard
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Bulk
Operating Temperature -55°C~150°C TJ

Physical

Supplier Device Package TO-247AC
Package / Case TO-247-3
Mounting Type Through Hole
