IKW03N120H2FKSA1

Rochester Electronics, LLC
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Tube Through Hole ROHS3Compliant IGBT Transistor 2.8V @ 15V 3A 9.6A 62.5W 42ns
PDF
/
Inventory: 1621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Supplier Device Package PG-TO247-3
Package / Case TO-247-3
Mounting Type Through Hole

Technical

Operating Temperature -40°C~150°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Input Type Standard
Power - Max 62.5W
Reverse Recovery Time 42ns
Voltage - Collector Emitter Breakdown (Max) 1.2V
Current - Collector (Ic) (Max) 9.6A
Test Condition 800V, 3A, 82Ohm, 15V
Vce(on) (Max) @ Vge, Ic 2.8V @ 15V, 3A
Gate Charge 22nC
Current - Collector Pulsed (Icm) 9.9A
Td (on/off) @ 25°C 9.2ns/281ns
Switching Energy 290μJ

Compliance

RoHS Status ROHS3 Compliant
