IHW40T60FKSA1 image
Favorite
IHW40T60FKSA1 image
Favorite
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description TrenchStop? Tube Through Hole Trench Field Stop IGBT Transistor 2.05V @ 15V 40A 80A 303W 143ns
PDF
/
Buying Options
Total Price: USD $3.01
Unit Price: USD $3.0134
≥1 USD $3.0134
≥10 USD $2.47285
≥100 USD $2.39495
≥500 USD $2.318
≥1000 USD $2.24105
Inventory: 59501
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Switching Energy 920μJ
Td (on/off) @ 25°C -/186ns
Current - Collector Pulsed (Icm) 120A
Gate Charge 215nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 2.05V @ 15V, 40A
Test Condition 400V, 40A, 5.6Ohm, 15V
Current - Collector (Ic) (Max) 80A
Voltage - Collector Emitter Breakdown (Max) 600V
Reverse Recovery Time 143ns
Power - Max 303W
Input Type Standard
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series TrenchStop?
Packaging Tube
Operating Temperature -40°C~175°C TJ

Physical

Supplier Device Package PG-TO247-3
Package / Case TO-247-3
Mounting Type Through Hole
