IHW40T120FKSA1
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
TrenchStop? Tube Through Hole Trench Field Stop IGBT Transistor 2.3V @ 15V 40A 75A 270W 195ns
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 487
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package PG-TO247-3
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Series TrenchStop?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Input Type Standard
Power - Max 270W
Reverse Recovery Time 195ns
Voltage - Collector Emitter Breakdown (Max) 1.2V
Current - Collector (Ic) (Max) 75A
Test Condition 600V, 40A, 15Ohm, 15V
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 40A
IGBT Type Trench Field Stop
Gate Charge 203nC
Current - Collector Pulsed (Icm) 105A
Td (on/off) @ 25°C 48ns/480ns
Switching Energy 6.5mJ
Compliance
RoHS Status ROHS3 Compliant
