NGTB60N65FL2WG
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
650V/60A IGBT FSII
PDF
/
Buying Options
Total Price: USD $32.52
Unit Price: USD $32.520712
≥1 USD $32.520712
≥10 USD $30.67991
≥100 USD $28.943315
≥500 USD $27.305017
≥1000 USD $25.759456
Inventory: 1170
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Published 2015
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 595W
Input Type Standard
Power - Max 595W
Collector Emitter Voltage (VCEO) 2V
Max Collector Current 100A
Reverse Recovery Time 96 ns
Collector Emitter Breakdown Voltage 650V
Collector Emitter Saturation Voltage 1.64V
Test Condition 400V, 60A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 60A
IGBT Type Field Stop
Gate Charge 318nC
Current - Collector Pulsed (Icm) 240A
Td (on/off) @ 25°C 117ns/265ns
Switching Energy 1.59mJ (on), 660μJ (off)
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
