FGPF15N60UNDF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT Transistors 600V, 15A Short Circuit Rated IGBT
PDF
/
Buying Options
Total Price: USD $6.91
Unit Price: USD $6.91315
≥1 USD $6.91315
≥10 USD $5.67245
≥100 USD $5.4948
≥500 USD $5.31715
≥1000 USD $5.14045
Inventory: 1568
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2.74mm
Length 10.36mm
Height 16.07mm
Technical
Fall Time-Max (tf) 12.8 ns
Gate-Emitter Thr Voltage-Max 8.5V
Gate-Emitter Voltage-Max 20V
Switching Energy 370μJ (on), 67μJ (off)
Td (on/off) @ 25°C 9.3ns/54.8ns
Current - Collector Pulsed (Icm) 45A
Gate Charge 43nC
IGBT Type NPT
Turn Off Time-Nom (toff) 69.8 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 15A
Test Condition 400V, 15A, 10 Ω, 15V
Turn On Time 18.8 ns
Collector Emitter Saturation Voltage 2.2V
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-220AB
Reverse Recovery Time 82.4 ns
Max Collector Current 30A
Collector Emitter Voltage (VCEO) 600V
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 42W
Input Type Standard
Case Connection ISOLATED
Element Configuration Single
Number of Elements 1
Max Power Dissipation 42W
Subcategory Insulated Gate BIP Transistors
HTS Code 8541.29.00.95
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2013
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 2.27g
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 hours ago)
Factory Lead Time 13 Weeks
