FGL60N100DTU

ON Semiconductor
RoHS
/
Package TO-264-3, TO-264AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description IGBT 1000V 60A 176W TO264
PDF
/
Inventory: 9458
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Current - Collector Pulsed (Icm) 120A
Gate Charge 230nC
IGBT Type Trench
Vce(on) (Max) @ Vge, Ic 2.9V @ 15V, 60A
Current - Collector (Ic) (Max) 60A
Voltage - Collector Emitter Breakdown (Max) 1000V
Reverse Recovery Time 1.5μs
Power - Max 176W
Input Type Standard
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature -55°C~150°C TJ

Physical

Supplier Device Package TO-264-3
Package / Case TO-264-3, TO-264AA
Mounting Type Through Hole
