APT40GR120B2SCD10
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 1.2KV 88A 3-Pin(3+Tab) TO-247
PDF
/
Buying Options
Total Price: USD $103.06
Unit Price: USD $103.0636
≥1 USD $103.0636
≥10 USD $99.7386
≥100 USD $96.41455
≥500 USD $86.4405
Inventory: 2110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2001
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Power Dissipation 500W
Element Configuration Single
Input Type Standard
Turn On Delay Time 20 ns
Power - Max 500W
Turn-Off Delay Time 166 ns
Collector Emitter Voltage (VCEO) 3.2V
Max Collector Current 88A
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Test Condition 600V, 40A, 4.3 Ω, 15V
Vce(on) (Max) @ Vge, Ic 3.2V @ 15V, 40A
IGBT Type NPT
Gate Charge 210nC
Current - Collector Pulsed (Icm) 160A
Td (on/off) @ 25°C 20ns/166ns
Switching Energy 929μJ (on), 1070μJ (off)
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
