NGD8205ANT4G

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description IGBT 390V 20A 125W DPAK-3
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
Inventory: 1163
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Td (on/off) @ 25°C -/5μs
Current - Collector Pulsed (Icm) 50A
Vce(on) (Max) @ Vge, Ic 1.9V @ 4.5V, 20A
Test Condition 300V, 9A, 1k Ω, 5V
Current - Collector (Ic) (Max) 20A
Voltage - Collector Emitter Breakdown (Max) 390V
Power - Max 125W
Input Type Logic
Base Part Number NGD8205
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ

Physical

Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 29 Weeks
