IXYT30N65C3H1HV
RoHS
RoHS compliant
RoHS compliantPackage TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 650V 60A 270W TO268HV
PDF
/
Inventory: 8750
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Published 2014
Series GenX3?, XPT?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 270W
Reach Compliance Code not_compliant
Element Configuration Single
Input Type Standard
Power - Max 270W
Collector Emitter Voltage (VCEO) 2.7V
Max Collector Current 60A
Reverse Recovery Time 120 ns
Collector Emitter Breakdown Voltage 650V
Collector Emitter Saturation Voltage 2.35V
Test Condition 400V, 30A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 30A
IGBT Type PT
Gate Charge 44nC
Current - Collector Pulsed (Icm) 118A
Td (on/off) @ 25°C 21ns/75ns
Switching Energy 1mJ (on), 270μJ (off)
Compliance
RoHS Status ROHS3 Compliant
