IXYA20N120C4HV
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 1200V 20A X4 HSPEED TO263D2
PDF
/
Buying Options
Total Price: USD $9.52
Unit Price: USD $9.5216
≥1 USD $9.5216
≥10 USD $7.599856
≥100 USD $6.799936
≥500 USD $5.999928
≥1000 USD $5.399944
Inventory: 230
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Technical
Operating Temperature -55°C~175°C TJ
Series GenX4?, XPT?
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Input Type Standard
Power - Max 375W
Reverse Recovery Time 53ns
Voltage - Collector Emitter Breakdown (Max) 1200V
Current - Collector (Ic) (Max) 68A
Test Condition 800mV, 20A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 20A
IGBT Type PT
Gate Charge 44nC
Current - Collector Pulsed (Icm) 120A
Td (on/off) @ 25°C 14ns/160ns
Switching Energy 4.4mJ (on), 1mJ (off)
Compliance
RoHS Status ROHS3 Compliant
