IXGT40N60B2
RoHS
/
Package TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 75A 3-Pin(2+Tab) TO-268
PDF
/
Inventory: 5142
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Weight 4.500005g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2003
Series HiPerFAST?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 300W
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number IXG*40N60
Pin Count 4
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Case Connection COLLECTOR
Input Type Standard
Power - Max 300W
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 75A
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 1.7V
Turn On Time 38 ns
Test Condition 400V, 30A, 3.3 Ω, 15V
Vce(on) (Max) @ Vge, Ic 1.7V @ 15V, 30A
Turn Off Time-Nom (toff) 390 ns
IGBT Type PT
Gate Charge 100nC
Current - Collector Pulsed (Icm) 200A
Td (on/off) @ 25°C 18ns/130ns
Switching Energy 400μJ (off)
Compliance
RoHS Status RoHS Compliant
Alternative Model
