IXGT30N60C2
RoHS
/
Package TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 70A 3-Pin(2+Tab) TO-268
PDF
/
Inventory: 8555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Weight 1.59999g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2005
Series HiPerFAST?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 190W
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number IXG*30N60
Pin Count 4
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Case Connection COLLECTOR
Input Type Standard
Power - Max 190W
Transistor Application MOTOR CONTROL
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 70A
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.5V
Turn On Time 30 ns
Test Condition 400V, 24A, 5 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 24A
Turn Off Time-Nom (toff) 250 ns
IGBT Type PT
Gate Charge 70nC
Current - Collector Pulsed (Icm) 150A
Td (on/off) @ 25°C 13ns/70ns
Switching Energy 290μJ (off)
Compliance
RoHS Status RoHS Compliant
