IXGT2N250
RoHS
RoHS compliant
RoHS compliantPackage TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 2500V 5.5A 32W TO-268
PDF
/
Buying Options
Total Price: USD $57.31
Unit Price: USD $57.3144
≥1 USD $57.3144
≥10 USD $50.1512
≥100 USD $46.56887
Inventory: 39
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Gate-Emitter Thr Voltage-Max 5.5V
Gate-Emitter Voltage-Max 20V
Current - Collector Pulsed (Icm) 13.5A
Gate Charge 10.5nC
Turn Off Time-Nom (toff) 278 ns
Vce(on) (Max) @ Vge, Ic 3.1V @ 15V, 2A
Turn On Time 115 ns
Voltage - Collector Emitter Breakdown (Max) 2500V
Collector Emitter Breakdown Voltage 2.5kV
Max Collector Current 5.5A
Collector Emitter Voltage (VCEO) 3.1V
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 32W
Input Type Standard
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Max Power Dissipation 32W
Subcategory Insulated Gate BIP Transistors
Additional Feature LOW CONDUCTION LOSS
Terminal Finish Matte Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
