IXGR40N60C2
RoHS
/
Package ISOPLUS247?
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 56A 170W ISOPLUS247
PDF
/
Inventory: 7435
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Switching Energy 200μJ (off)
Td (on/off) @ 25°C 18ns/90ns
Current - Collector Pulsed (Icm) 200A
Gate Charge 95nC
IGBT Type PT
Turn Off Time-Nom (toff) 210 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 30A
Test Condition 400V, 30A, 3 Ω, 15V
Turn On Time 38 ns
Collector Emitter Saturation Voltage 2.7V
Collector Emitter Breakdown Voltage 600V
Max Collector Current 56A
Collector Emitter Voltage (VCEO) 600V
Rise Time 32ns
Transistor Application POWER CONTROL
Input Type Standard
Case Connection ISOLATED
Power Dissipation 170W
Element Configuration Single
Polarity NPN
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number IXG*40N60
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 170W
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series HiPerFAST?
Published 2005
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case ISOPLUS247?
Mounting Type Through Hole
Mount Through Hole
