IXGR120N60B
RoHS
/
Package ISOPLUS247?
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 156A 3-Pin(3+Tab) ISOPLUS 247
PDF
/
Inventory: 2266
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case ISOPLUS247?
Number of Pins 247
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2004
Series HiPerFAST?
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Power Dissipation 520W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number IXG*120N60
Pin Count 3
JESD-30 Code R-PSIP-T3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Case Connection ISOLATED
Input Type Standard
Power - Max 520W
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 156A
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.1V
Turn On Time 120 ns
Test Condition 480V, 100A, 2.4 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 100A
Turn Off Time-Nom (toff) 540 ns
IGBT Type PT
Gate Charge 350nC
Current - Collector Pulsed (Icm) 300A
Td (on/off) @ 25°C 60ns/200ns
Switching Energy 2.4mJ (on), 5.5mJ (off)
Compliance
RoHS Status RoHS Compliant
