IXGH50N60B2
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 75A 400W TO247
PDF
/
Inventory: 7821
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.3mm
Length 16.26mm
Height 21.46mm
Technical
Switching Energy 550μJ (off)
Td (on/off) @ 25°C 18ns/190ns
Current - Collector Pulsed (Icm) 200A
Gate Charge 140nC
IGBT Type PT
Turn Off Time-Nom (toff) 430 ns
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 40A
Test Condition 480V, 40A, 5 Ω, 15V
Turn On Time 43 ns
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-247AD
Max Collector Current 75A
Collector Emitter Voltage (VCEO) 600V
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 400W
Input Type Standard
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number IXG*50N60
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 400W
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series HiPerFAST?
Published 2004
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 6.500007g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
