IXGH34N60B2
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 70A 190W TO247AD
PDF
/
Inventory: 6325
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Switching Energy 640μJ (off)
Td (on/off) @ 25°C 13ns/150ns
Current - Collector Pulsed (Icm) 150A
Gate Charge 66nC
Turn Off Time-Nom (toff) 300 ns
Vce(on) (Max) @ Vge, Ic 1.55V @ 15V, 24A
Test Condition 400V, 24A, 5 Ω, 15V
Turn On Time 28 ns
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-247AD
Max Collector Current 70A
Collector Emitter Voltage (VCEO) 1.55V
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 190W
Input Type Standard
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 190W
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series HiPerFAST?
Published 2005
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
