IXGH30N60C2
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 70A 3-Pin(3+Tab) TO-247
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1477
≥1 USD $4.1477
≥10 USD $3.40385
≥100 USD $3.29745
≥500 USD $3.19105
≥1000 USD $3.08465
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Switching Energy 290μJ (off)
Td (on/off) @ 25°C 13ns/70ns
Current - Collector Pulsed (Icm) 150A
Gate Charge 70nC
IGBT Type PT
Turn Off Time-Nom (toff) 250 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 24A
Test Condition 400V, 24A, 5 Ω, 15V
Turn On Time 30 ns
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-247AD
Max Collector Current 70A
Collector Emitter Voltage (VCEO) 600V
Turn-Off Delay Time 500 ns
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 190W
Turn On Delay Time 13 ns
Input Type Standard
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number IXG*30N60
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 190W
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series HiPerFAST?
Published 2005
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 6.500007g
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
