IXGH16N60C2D1
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 40A 150W TO247
PDF
/
Inventory: 3160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Gate-Emitter Thr Voltage-Max 5.5V
Gate-Emitter Voltage-Max 20V
Switching Energy 160μJ (on), 90μJ (off)
Td (on/off) @ 25°C 16ns/75ns
Current - Collector Pulsed (Icm) 100A
Gate Charge 25nC
IGBT Type PT
Turn Off Time-Nom (toff) 190 ns
Vce(on) (Max) @ Vge, Ic 3V @ 15V, 12A
Test Condition 400V, 12A, 22 Ω, 15V
Turn On Time 43 ns
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-247AD
Reverse Recovery Time 30 ns
Max Collector Current 40A
Collector Emitter Voltage (VCEO) 600V
Turn-Off Delay Time 60 ns
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 150W
Turn On Delay Time 25 ns
Input Type Standard
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number IXG*16N60
Max Power Dissipation 150W
Subcategory Insulated Gate BIP Transistors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series HiPerFAST?
Published 2010
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 6.500007g
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
