IXGH16N170
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 1.7KV 32A 3-Pin(3+Tab) TO-247AD
PDF
/
Buying Options
Total Price: USD $17.67
Unit Price: USD $17.67468
≥1 USD $17.67468
≥10 USD $16.67422
≥100 USD $15.7304
≥500 USD $14.84
≥1000 USD $14
≥3000 USD $13.20755
Inventory: 7402
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Through Hole
Transistor Element Material SILICON
Weight 6.500007g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Length 16.26mm
Height 21.46mm
Technical
Fall Time-Max (tf) 1100 ns
Gate-Emitter Thr Voltage-Max 5V
Gate-Emitter Voltage-Max 20V
Switching Energy 9.3mJ (off)
Td (on/off) @ 25°C 45ns/400ns
Current - Collector Pulsed (Icm) 80A
Gate Charge 78nC
IGBT Type NPT
Turn Off Time-Nom (toff) 1600 ns
Vce(on) (Max) @ Vge, Ic 3.5V @ 15V, 16A
Test Condition 1360V, 16A, 10 Ω, 15V
Turn On Time 90 ns
Collector Emitter Saturation Voltage 2.7V
Voltage - Collector Emitter Breakdown (Max) 1700V
Collector Emitter Breakdown Voltage 1.7kV
JEDEC-95 Code TO-268AA
Max Collector Current 32A
Collector Emitter Voltage (VCEO) 1.7kV
Turn-Off Delay Time 200 ns
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Turn On Delay Time 45 ns
Input Type Standard
Case Connection COLLECTOR
Power Dissipation 190W
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number IXG*16N170
Terminal Form GULL WING
Max Power Dissipation 190W
Subcategory Insulated Gate BIP Transistors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2006
Packaging Tube
Operating Temperature -55°C~150°C TJ
