IXGC16N60C2D1
RoHS
/
Package ISOPLUS220?
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IXYS SEMICONDUCTOR IXGC16N60C2D1 IGBT Single Transistor, 20 A, 3 V, 63 W, ISOPLUS-220, 3 Pins
PDF
/
Inventory: 5169
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Switching Energy 60μJ (off)
Td (on/off) @ 25°C 25ns/60ns
Current - Collector Pulsed (Icm) 100A
Gate Charge 32nC
IGBT Type PT
Turn Off Time-Nom (toff) 185 ns
Vce(on) (Max) @ Vge, Ic 3V @ 15V, 12A
Test Condition 400V, 12A, 22 Ω, 15V
Turn On Time 43 ns
Collector Emitter Saturation Voltage 3V
Collector Emitter Breakdown Voltage 600V
Reverse Recovery Time 30ns
Max Collector Current 20A
Collector Emitter Voltage (VCEO) 600V
Rise Time 35ns
Transistor Application MOTOR CONTROL
Input Type Standard
Case Connection ISOLATED
Power Dissipation 63W
Element Configuration Single
Polarity NPN
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Base Part Number IXG*16N60
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 63W
Additional Feature UL RECOGNIZED
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Termination Through Hole
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series HiPerFAST?
Published 2004
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 220
Package / Case ISOPLUS220?
Mounting Type Through Hole
Mount Through Hole
