IXDR35N60BD1
RoHS
RoHS compliant
RoHS compliantPackage ISOPLUS247?
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 38A 125W ISOPLUS247
PDF
/
Inventory: 9705
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Switching Energy 1.6mJ (on), 800μJ (off)
Current - Collector Pulsed (Icm) 48A
Gate Charge 140nC
IGBT Type NPT
Turn Off Time-Nom (toff) 390 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 35A
Test Condition 300V, 35A, 10 Ω, 15V
Turn On Time 75 ns
Collector Emitter Saturation Voltage 2.2V
Collector Emitter Breakdown Voltage 600V
Reverse Recovery Time 40ns
Max Collector Current 38A
Collector Emitter Voltage (VCEO) 600V
Turn-Off Delay Time 320 ns
Rise Time 70ns
Transistor Application POWER CONTROL
Turn On Delay Time 30 ns
Input Type Standard
Case Connection ISOLATED
Power Dissipation 125W
Element Configuration Single
Polarity NPN
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number IXD*35N60
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 125W
Additional Feature HIGH SPEED
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2006
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case ISOPLUS247?
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 32 Weeks
