IXDP20N60B
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 32A 140W TO220AB
PDF
/
Inventory: 1422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Energy 900μJ (on), 400μJ (off)
Current - Collector Pulsed (Icm) 40A
Gate Charge 70nC
IGBT Type NPT
Turn Off Time-Nom (toff) 315 ns
Vce(on) (Max) @ Vge, Ic 2.8V @ 15V, 20A
Test Condition 300V, 20A, 22 Ω, 15V
Turn On Time 55 ns
Collector Emitter Saturation Voltage 2.2V
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-220AB
Max Collector Current 32A
Collector Emitter Voltage (VCEO) 600V
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Input Type Standard
Case Connection COLLECTOR
Power Dissipation 140W
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 140W
Additional Feature HIGH SPEED
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 2.299997g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 32 Weeks
