IXBL64N250
RoHS
RoHS compliant
RoHS compliantPackage ISOPLUSi5-Pak?
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 2500V 116A 500W ISOPLUSI5
PDF
/
Buying Options
Total Price: USD $298.55
Unit Price: USD $298.55346
≥1 USD $298.55346
≥200 USD $119.124669
≥500 USD $115.143956
≥1000 USD $113.177232
Inventory: 3269
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Gate-Emitter Thr Voltage-Max 5V
Gate-Emitter Voltage-Max 25V
Current - Collector Pulsed (Icm) 750A
Gate Charge 400nC
Turn Off Time-Nom (toff) 397 ns
Vce(on) (Max) @ Vge, Ic 3V @ 15V, 64A
Turn On Time 632 ns
Voltage - Collector Emitter Breakdown (Max) 2500V
Collector Emitter Breakdown Voltage 2.5kV
Reverse Recovery Time 160 ns
Max Collector Current 116A
Collector Emitter Voltage (VCEO) 3V
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 500W
Input Type Standard
Case Connection ISOLATED
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 4
Terminal Position SINGLE
Max Power Dissipation 500W
Subcategory Insulated Gate BIP Transistors
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series BIMOSFET?
Published 2010
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Package / Case ISOPLUSi5-Pak?
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 24 Weeks
