SIGC11T60SNCX1SA2

Infineon Technologies
RoHS
RoHS RoHS compliant
Package Die
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description IGBT 3 CHIP 600V WAFER
PDF
/
Inventory: 5562
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Td (on/off) @ 25°C 28ns/198ns
Current - Collector Pulsed (Icm) 30A
IGBT Type NPT
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 10A
Test Condition 400V, 10A, 25Ohm, 15V
Current - Collector (Ic) (Max) 10A
Voltage - Collector Emitter Breakdown (Max) 600V
Input Type Standard
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Operating Temperature -55°C~150°C TJ

Physical

Supplier Device Package Die
Package / Case Die
Mounting Type Surface Mount
