SIGC05T60SNCX1SA4
RoHS
RoHS compliant
RoHS compliantPackage Die
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 3 CHIP 600V WAFER
PDF
/
Inventory: 8752
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Td (on/off) @ 25°C 22ns/264ns
Current - Collector Pulsed (Icm) 12A
IGBT Type NPT
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 4A
Test Condition 400V, 4A, 67 Ω, 15V
Current - Collector (Ic) (Max) 4A
Voltage - Collector Emitter Breakdown (Max) 600V
Input Type Standard
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Published 2016
Operating Temperature -55°C~150°C TJ
Physical
Package / Case Die
Mounting Type Surface Mount
