SGW15N60FKSA1
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 31A 3-Pin(3+Tab) TO-247
PDF
/
Buying Options
Total Price: USD $3.27
Unit Price: USD $3.26705
≥1 USD $3.26705
≥10 USD $2.6809
≥100 USD $2.5973
≥500 USD $2.5137
≥1000 USD $2.42915
Inventory: 44303
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2008
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Additional Feature LOW CONDUCTION LOSS
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Case Connection COLLECTOR
Input Type Standard
Power - Max 139W
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
JEDEC-95 Code TO-247AC
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 31A
Turn On Time 54 ns
Test Condition 400V, 15A, 21 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 15A
Turn Off Time-Nom (toff) 315 ns
IGBT Type NPT
Gate Charge 76nC
Current - Collector Pulsed (Icm) 62A
Td (on/off) @ 25°C 32ns/234ns
Switching Energy 570μJ
Compliance
RoHS Status RoHS Compliant
