IRGS14C40LPBF
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Surface Mount N-CHANNEL Single IGBT Transistor 1.75V @ 5V 14A 14A 125W 2.8ns
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2445
≥1 USD $1.2445
≥10 USD $1.02125
≥100 USD $0.9899
≥500 USD $0.9576
≥1000 USD $0.9253
Inventory: 1144
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~175°C TJ
Packaging Tube
Published 2000
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish MATTE TIN OVER NICKEL
Additional Feature LOW SATURATION VOLTAGE
Subcategory Insulated Gate BIP Transistors
Voltage - Rated DC 430V
Max Power Dissipation 125W
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 14A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number IRGS14C40LPBF
JESD-30 Code R-PSSO-G2
Number of Elements 1
Element Configuration Single
Power Dissipation 125W
Input Type Logic
Turn On Delay Time 900 ns
Transistor Application AUTOMOTIVE IGNITION
Rise Time 2.8ns
Polarity/Channel Type N-CHANNEL
Turn-Off Delay Time 6 μs
Collector Emitter Voltage (VCEO) 1.75V
Max Collector Current 20A
Collector Emitter Breakdown Voltage 430V
Collector Emitter Saturation Voltage 1.4V
Turn On Time 3700 ns
Vce(on) (Max) @ Vge, Ic 1.75V @ 5V, 14A
Gate Charge 27nC
Td (on/off) @ 25°C 900ns/6μs
Gate-Emitter Voltage-Max 12V
Gate-Emitter Thr Voltage-Max 2.2V
Dimensions
Height 4.699mm
Length 10.668mm
Width 4.83mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
