IRGB30B60K
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 78A 370W TO220AB
PDF
/
Buying Options
Total Price: USD $20.52
Unit Price: USD $20.52095
≥1 USD $20.52095
≥10 USD $16.8378
≥100 USD $16.3115
≥500 USD $15.7852
≥1000 USD $15.2589
Inventory: 2699
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Switching Energy 350μJ (on), 825μJ (off)
Td (on/off) @ 25°C 46ns/185ns
Current - Collector Pulsed (Icm) 120A
Gate Charge 102nC
IGBT Type NPT
Turn Off Time-Nom (toff) 237 ns
Vce(on) (Max) @ Vge, Ic 2.35V @ 15V, 30A
Test Condition 400V, 30A, 10 Ω, 15V
Turn On Time 74 ns
Current - Collector (Ic) (Max) 78A
Voltage - Collector Emitter Breakdown (Max) 600V
JEDEC-95 Code TO-220AB
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 370W
Input Type Standard
Case Connection COLLECTOR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2005
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
