IRG4PSC71KPBF
RoHS
/
Package TO-274AA
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Bulk Through Hole N-CHANNEL Single IGBT Transistor 2.3V @ 15V 60A 200A 350W 54ns
PDF
/
Buying Options
Total Price: USD $3.59
Unit Price: USD $3.5948
≥1 USD $3.5948
≥10 USD $2.94975
≥100 USD $2.8576
≥500 USD $2.76545
≥1000 USD $2.6733
Inventory: 1188
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead, Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.5mm
Length 16.0782mm
Height 20.8mm
Technical
Switching Energy 790μJ (on), 1.98mJ (off)
Td (on/off) @ 25°C 34ns/54ns
Current - Collector Pulsed (Icm) 200A
Gate Charge 340nC
Turn Off Time-Nom (toff) 533 ns
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 60A
Test Condition 480V, 60A, 5 Ω, 15V
Turn On Time 93 ns
Collector Emitter Saturation Voltage 2.3V
Collector Emitter Breakdown Voltage 600V
Max Collector Current 85A
Collector Emitter Voltage (VCEO) 2.3V
Turn-Off Delay Time 251 ns
Polarity/Channel Type N-CHANNEL
Rise Time 54ns
Transistor Application MOTOR CONTROL
Turn On Delay Time 34 ns
Input Type Standard
Case Connection COLLECTOR
Power Dissipation 350W
Element Configuration Single
Number of Elements 1
Current Rating 85A
Max Power Dissipation 350W
Voltage - Rated DC 600V
Additional Feature LOW CONDUCTION LOSS
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1999
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-274AA
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
