IRG4PH30KD
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 1200V 20A 100W TO247AC
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.6448
≥100 USD $2.56215
≥500 USD $2.4795
≥1000 USD $2.39685
Inventory: 11
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Switching Energy 950μJ (on), 1.15mJ (off)
Td (on/off) @ 25°C 39ns/220ns
Current - Collector Pulsed (Icm) 40A
Gate Charge 53nC
Turn Off Time-Nom (toff) 637 ns
Vce(on) (Max) @ Vge, Ic 4.2V @ 15V, 10A
Test Condition 800V, 10A, 23 Ω, 15V
Turn On Time 121 ns
Current - Collector (Ic) (Max) 20A
Voltage - Collector Emitter Breakdown (Max) 1200V
JEDEC-95 Code TO-247AC
Reverse Recovery Time 50ns
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 100W
Input Type Standard
Case Connection COLLECTOR
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Additional Feature LOW CONDUCTION LOSS
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2000
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-247-3
Mounting Type Through Hole
Alternative Model
