IRG4PC30WPBF
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 23A 100W TO247AC
PDF
/
Buying Options
Total Price: USD $4.79
Unit Price: USD $4.7918
≥1 USD $4.7918
≥10 USD $3.9311
≥100 USD $3.80855
≥500 USD $3.686
≥1000 USD $3.5625
Inventory: 1204
Minimum: 1
-
+
Technical Details
Physical
Transistor Element Material SILICON
Weight 38.000013g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.3mm
Length 15.875mm
Height 20.2946mm
Technical
Fall Time-Max (tf) 100 ns
Gate-Emitter Thr Voltage-Max 6V
Gate-Emitter Voltage-Max 20V
Switching Energy 130μJ (on), 130μJ (off)
Td (on/off) @ 25°C 25ns/99ns
Current - Collector Pulsed (Icm) 92A
Gate Charge 51nC
Turn Off Time-Nom (toff) 300 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 12A
Test Condition 480V, 12A, 23 Ω, 15V
Turn On Time 41 ns
Collector Emitter Saturation Voltage 2.7V
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-247AC
Max Collector Current 23A
Collector Emitter Voltage (VCEO) 2.7V
Polarity/Channel Type N-CHANNEL
Rise Time 16 ns
Transistor Application POWER CONTROL
Input Type Standard
Case Connection COLLECTOR
Power Dissipation 100W
Element Configuration Dual
Number of Elements 1
Current Rating 23A
Terminal Position SINGLE
Max Power Dissipation 100W
Voltage - Rated DC 600V
Subcategory Insulated Gate BIP Transistors
Additional Feature LOW CONDUCTION LOSS
ECCN Code EAR99
Termination Through Hole
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2000
Packaging Bulk
Operating Temperature -55°C~150°C TJ
