IRG4PC30SPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 34A 100W TO247AC
PDF
/
Buying Options
Total Price: USD $8.55
Unit Price: USD $8.54525
≥1 USD $8.54525
≥10 USD $7.01195
≥100 USD $6.7925
≥500 USD $6.574
≥1000 USD $6.35455
Inventory: 1373
Minimum: 1
-
+
Technical Details
Technical
Max Collector Current 34A
JEDEC-95 Code TO-247AC
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 1.6V
Turn On Time 40 ns
Test Condition 480V, 18A, 23 Ω, 15V
Vce(on) (Max) @ Vge, Ic 1.6V @ 15V, 18A
Turn Off Time-Nom (toff) 1550 ns
Gate Charge 50nC
Current - Collector Pulsed (Icm) 68A
Td (on/off) @ 25°C 22ns/540ns
Switching Energy 260μJ (on), 3.45mJ (off)
Gate-Emitter Voltage-Max 20V
Gate-Emitter Thr Voltage-Max 6V
Fall Time-Max (tf) 590 ns
Collector Emitter Voltage (VCEO) 1.6V
Polarity/Channel Type N-CHANNEL
Rise Time 19 ns
Transistor Application POWER CONTROL
Input Type Standard
Case Connection COLLECTOR
Power Dissipation 100W
Element Configuration Dual
Number of Elements 1
Current Rating 34A
Terminal Position SINGLE
Max Power Dissipation 100W
Voltage - Rated DC 600V
Subcategory Insulated Gate BIP Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Published 2003
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Dimensions
Height 20.2946mm
Length 15.875mm
Width 5.3086mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Transistor Element Material SILICON
Weight 38.000013g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
