IRG4BC30S-SPBF
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 34A 100W D2PAK
PDF
/
Buying Options
Total Price: USD $4.89
Unit Price: USD $4.88965
≥1 USD $4.88965
≥10 USD $4.01185
≥100 USD $3.88645
≥500 USD $3.76105
≥1000 USD $3.63565
Inventory: 1167
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Supplier Device Package D2PAK
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2010
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 600V
Max Power Dissipation 100W
Current Rating 34A
Base Part Number IRG4BC30S-SPBF
Element Configuration Single
Power Dissipation 100W
Input Type Standard
Turn On Delay Time 22 ns
Power - Max 100W
Rise Time 18ns
Turn-Off Delay Time 540 ns
Collector Emitter Voltage (VCEO) 1.6V
Max Collector Current 34A
Collector Emitter Breakdown Voltage 600V
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 34A
Collector Emitter Saturation Voltage 1.6V
Test Condition 480V, 18A, 23Ohm, 15V
Vce(on) (Max) @ Vge, Ic 1.6V @ 15V, 18A
Gate Charge 50nC
Current - Collector Pulsed (Icm) 68A
Td (on/off) @ 25°C 22ns/540ns
Switching Energy 260μJ (on), 3.45mJ (off)
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
