IRG4BC20K
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 16A 60W TO220AB
PDF
/
Buying Options
Total Price: USD $1.84
Unit Price: USD $1.8373
≥1 USD $1.8373
≥10 USD $1.50765
≥100 USD $1.4611
≥500 USD $1.4136
≥1000 USD $1.3661
Inventory: 4607
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Fall Time-Max (tf) 110ns
Gate-Emitter Thr Voltage-Max 6V
Gate-Emitter Voltage-Max 20V
Switching Energy 150μJ (on), 250μJ (off)
Td (on/off) @ 25°C 28ns/150ns
Current - Collector Pulsed (Icm) 32A
Gate Charge 34nC
Turn Off Time-Nom (toff) 380 ns
Vce(on) (Max) @ Vge, Ic 2.8V @ 15V, 9A
Test Condition 480V, 9A, 50 Ω, 15V
Turn On Time 88 ns
Power Dissipation-Max (Abs) 60W
Current - Collector (Ic) (Max) 16A
Voltage - Collector Emitter Breakdown (Max) 600V
JEDEC-95 Code TO-220AB
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 60W
Input Type Standard
Case Connection COLLECTOR
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Subcategory Insulated Gate BIP Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2000
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
