IKP06N60TXKSA1
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 12A 3-Pin(3+Tab) TO-220AB
PDF
/
Buying Options
Total Price: USD $1.46
Unit Price: USD $1.4608
≥1 USD $1.4608
≥10 USD $1.171808
≥100 USD $0.928576
≥500 USD $0.787072
≥1000 USD $0.641159
≥3000 USD $0.603574
Inventory: 1150
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~175°C TJ
Packaging Tube
Published 2008
Series TrenchStop?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin (Sn)
Max Power Dissipation 88W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Case Connection COLLECTOR
Input Type Standard
Power - Max 88W
Transistor Application POWER CONTROL
Halogen Free Halogen Free
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 12A
Reverse Recovery Time 123 ns
JEDEC-95 Code TO-220AB
Collector Emitter Breakdown Voltage 600V
Turn On Time 17 ns
Test Condition 400V, 6A, 23 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.05V @ 15V, 6A
Turn Off Time-Nom (toff) 249 ns
IGBT Type Trench Field Stop
Gate Charge 42nC
Current - Collector Pulsed (Icm) 18A
Td (on/off) @ 25°C 9ns/130ns
Switching Energy 200μJ
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
