AOK50B60D1
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 100A 312W TO247
PDF
/
Buying Options
Total Price: USD $4.3
Unit Price: USD $4.3032
≥1 USD $4.3032
≥10 USD $3.40824
≥100 USD $2.92131
≥500 USD $2.596722
≥1000 USD $2.223443
≥3000 USD $2.093599
Inventory: 129
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Gate-Emitter Voltage-Max 20V
Switching Energy 2.37mJ (on), 500μJ (off)
Td (on/off) @ 25°C 26ns/68ns
Current - Collector Pulsed (Icm) 168A
Gate Charge 64nC
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 50A
Test Condition 400V, 50A, 6 Ω, 15V
Collector Emitter Breakdown Voltage 600V
Reverse Recovery Time 132 ns
Max Collector Current 100A
Collector Emitter Voltage (VCEO) 2.4V
Polarity/Channel Type N-CHANNEL
Power - Max 312W
Input Type Standard
Max Power Dissipation 312W
Subcategory Insulated Gate BIP Transistors
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Alpha IGBT?
Published 2011
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
