AOD5B65N1
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 650V 5A TO252
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 3252
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Energy 81μJ (on), 49μJ (off)
Td (on/off) @ 25°C 8ns/73ns
Current - Collector Pulsed (Icm) 15A
Gate Charge 9.2nC
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 5A
Test Condition 400V, 5A, 60 Ω, 15V
Current - Collector (Ic) (Max) 10A
Voltage - Collector Emitter Breakdown (Max) 650V
Reverse Recovery Time 170ns
Power - Max 52W
Input Type Standard
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Alpha IGBT?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
