CM100TX-24S1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
POWEREX CM100TX-24S1IGBT, MODULE, 1.2KV, 100A
PDF
/
Buying Options
Total Price: USD $258.67
Unit Price: USD $258.6736
≥1 USD $258.6736
≥10 USD $231.91495
Inventory: 403
Minimum: 1
-
+
Technical Details
Physical
Package / Case Module
Number of Pins 35
Supplier Device Package Module
Technical
Operating Temperature -40°C~150°C TJ
Published 2013
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Max Power Dissipation 625W
Configuration Three Level Inverter
Power - Max 625W
Input Standard
Collector Emitter Voltage (VCEO) 2.25V
Max Collector Current 100A
Current - Collector Cutoff (Max) 1mA
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Current - Collector (Ic) (Max) 100A
Collector Emitter Saturation Voltage 1.8V
Input Capacitance 10nF
Vce(on) (Max) @ Vge, Ic 2.25V @ 15V, 100A
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 10nF @ 10V
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
