APTGT30DA170D1G
RoHS
RoHS compliant
RoHS compliantPackage D1
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
D1 Chassis Mount Trench Field Stop Single IGBT Module 2.5nF @ 25V 3mA 210W 965ns
PDF
/
Inventory: 1391
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case D1
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~150°C TJ
Published 2007
JESD-609 Code e1
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
Terminal Finish TIN SILVER COPPER
Max Power Dissipation 210W
Terminal Position UPPER
Terminal Form UNSPECIFIED
Pin Count 7
JESD-30 Code R-XUFM-X7
Number of Elements 1
Configuration Single
Case Connection ISOLATED
Power - Max 210W
Transistor Application MOTOR CONTROL
Polarity/Channel Type N-CHANNEL
Input Standard
Collector Emitter Voltage (VCEO) 2.4V
Max Collector Current 45A
Current - Collector Cutoff (Max) 3mA
Collector Emitter Breakdown Voltage 1.7kV
Voltage - Collector Emitter Breakdown (Max) 1700V
Input Capacitance 2.5nF
Turn On Time 330 ns
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 30A
Turn Off Time-Nom (toff) 965 ns
IGBT Type Trench Field Stop
NTC Thermistor No
Input Capacitance (Cies) @ Vce 2.5nF @ 25V
Compliance
RoHS Status RoHS Compliant
