APTGT300DA120G
RoHS
RoHS compliant
RoHS compliantPackage SP6
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
SP6 Chassis Mount Trench Field Stop Single IGBT Module 21nF @ 25V 500muA 1.38kW 610ns
PDF
/
Buying Options
Total Price: USD $497.76
Unit Price: USD $497.76109
≥1 USD $497.76109
≥200 USD $198.61026
≥500 USD $191.973551
≥1000 USD $188.693927
Inventory: 4995
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Input Capacitance (Cies) @ Vce 21nF @ 25V
NTC Thermistor No
IGBT Type Trench Field Stop
Turn Off Time-Nom (toff) 610 ns
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 300A
Turn On Time 340 ns
Input Capacitance 21nF
Voltage - Collector Emitter Breakdown (Max) 1200V
Collector Emitter Breakdown Voltage 1.2kV
Current - Collector Cutoff (Max) 500μA
Max Collector Current 420A
Collector Emitter Voltage (VCEO) 1.2kV
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 1380W
Case Connection ISOLATED
Configuration Single
Number of Elements 1
Pin Count 5
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 1.38kW
Additional Feature AVALANCHE RATED
Terminal Finish TIN SILVER COPPER
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2006
Operating Temperature -40°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 5
Package / Case SP6
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 36 Weeks
